PTZ Cameras

Professional Ptz Camera PTZ310 Aver

Product Code: AF-PTZ310

Brand
Aver
RRP $3,079.00

Unit of Measure
EACH



3 Year
Technical Specifications
Brands AVer
Native Resolution 1080p
  • Details
  • Downloads
  • Where to Buy
  • Ordering

PTZ310

Capture Events in Lifelike Quality

Professional PTZ Camera
AVer PTZ310 is available in white or grey and equipped versatile functions to suite every classroom, hospital, or business. Creating the superior video quality, the PTZ310 makes you feel the action in a scene!

12X Optical Zoom
Resounding image quality and a 12X optical zoom enable you to capture crystal-clear footage in any classroom, hall, or activity center.

Full HD Resolution
The PTZ310 provides outstanding image quality in full HD 1080p at 60fps. It also offers the best auto focus, auto exposure, and auto white balance performance.

Up to 255 Preset Locations
Always be prepared to capture every angle and change the recording view at a moment’s notice with up to 255 preset locations through VISCA via RS232 and RS422 functionality, and 10 preset locations through IR remote control.

Stable Motion Control
Fully optimize your recording with customizable speed settings from 0.1°to 200° per second that maximize the agility and precision of pan/tilt rotation motion control.

Seamless Tracking Between Your Preset Zones
AVer SmartShoot optimizes your camera controls for automatic and seamless content capturing between your preset areas. With SmartShoot’s preset zone tracking you can create an uncompromising multi-camera feel with just one PTZ310 across all your preset zones. Save effortand time, while providing your video with a huge variety of shooting ranges.

Fit Your FOV in Seconds
AVer’s new SmartFrame provides you with one-touch face targeting technology to create stunning video content fast. SmartFrame instantly adjusts your FOV to fit everyone on screen at stunning speed so you can start recording presentations, lectures, and more with no hassle. Perfect for capturing multiple people, SmartFrame makes video content capturing easy and enjoyable.


Specs

Camera
Image sensor
  • 1/2.8" 1080p 60fps Exmor CMOS
Effective Picture Elements
  • Approx. 2.1 megapixels
Output Resolution
  • Auto
  • 1080p@60, 1080p@59.94, 1080p@50, 1080i@60, 1080i@59.94, 1080i@50, 1080p@30, 1080p@29.97, 1080p@25, 720p@60, 720p@59.94, 720p@50
Minimum Illumination
  • 0.3 lux (IRE50, F1.6, 30fps)
S/N Ratio
  • > 50dB
Gain
  • Auto/Manual
TV Line
  • 600 (corner/wide)
Shutter Speed
  • 1/1s ~ 1/32,000s
Exposure Control
  • Auto, Manual, Priority AE (Shutter, IRIS), BLC
White Balance
  • Auto/Indoor/Outdoor/One-push/Manual (2500 - 10000)
Optical Zoom
  • 30X
Digital Zoom
  • 12X
Horizontal Viewing Angle
  • 67° (Wide) ~ 2.3° (Tele)
Focal length
  • f = 4.3mm (Wide) ~ 129mm (Tele)
Aperture (Iris)
  • F = 1.6 (Wide) ~ 4.7 (Tele)
Minimum Working Distance
  • 0.01m (Wide), 1.2m (Tele)
Pan/Tilt Angle
  • Pan: -+ 170° ; Tilt: +90°/-30°
Pan/Tilt Speed (manual)
  • Pan: 0.1~100°/sec, Tilt: 0.1~100°/sec
Preset Speed
  • Pan: 200°/sec, Tilt: 200°/sec
Preset Position
  • 10 (IR), 255 (RS232)
Camera Control - Interface
  • RS232 (DIN9) / RS422 (RJ45)
Camera Control - Protocol
  • VISCA (RS-232/RS422/IP), CGI (IP)
Image Processing
  • Noise Reduction (2/3D), Flip, Mirror
Power Frequency
  • Auto/50Hz/60Hz

Audio

Audio - Channel
  • 2ch (Stereo)
Audio - Codec
  • AAC-LC (48/44.1/32/24K), G.711/PCM
Audio - Sample Rate
  • 48/44.1/32/24/16/8Khz

Interface


Video Output
  • 3G-SDI, HDMI, IP, USB
Audio Output
  • 3G-SDI, HDMI, IP, USB

Audio Input
  • MIC/Line in

General

Power Requirement
  • AC100V-AC240V to DC12V/5A
PoE
  • POE+ (IEEE 802.3at), Class 4
Operating Condition
  • Temperature: 0°C ~ +40°C ; Humidity: 20% ~ 80%
Storage Condition
  • Temperature: -20°C ~ +60°C ; Humidity: 20% ~ 95%
Dimensions
  • L=180 mm,W= 145 mm,H= 183.5 mm
Weight
  • 1.62 kg
Application
  • Indoor
Security
  • Kensington slot
Remote Control
  • Infrared
Accessory
  • Remote control, 12V/5A power adapter

IP Streaming

Resolution
  • 1920x1080, 1280x720, 960x540, 640x480
Network Video Compress Format
  • H.264 (High Profile), MJPEG
Maximum Frame Rate
  • H.264: 60fps (1920x1080), MJPEG: 30fps (1920x1080)
Bit-rate Control Mode
  • VBR/CBR (selectable)
Range of Bit-rate setting
  • 512Kbps ~ 32Mbps
Network Interface
  • 10/100/1000Base-T
Multi-stream Capability
  • 2
Network Protocol
  • IPv4, TCP, UDP, ARP, IMCP, IGMP, HTTP, DHCP, RTP/RTCP, RTSP, VISCA over IP

USB

Connector
  • Micro-USB 2.0
Video Format
  • YUV, MJPEG, H.264
Maximum Video Resolution
  • Up to 1080p
USB Video Class
  • UVC1.1
USB Audio Class
  • UAC1.0

WebUI

Live Video Preview
  • Yes
Camera PTZ Control
  • Pan / Tilt / Zoom / Focus / Preset Control
Camera / Image Adjustment
  • Exposure / White Balance / Picture
Network Configuration
  • DHCP / IP Addr / Gateway / Netmask / DNS

Software Tools


Device IP Searching, Configuration Tool
  • Windows Application

* Specifications may vary depending on location and are subject to change without notice.
