LRS8 8 inch 2-way Coaxial Long Range Speaker - White

Product Code: AJ-LRS8

Brand
Australian Monitor
RRP $780.00


Quantity In Cart:
Unit of Measure
EACH



5 Year
Technical Specifications
Brands Australian Monitor
  • Details
  • Downloads
  • Where to Buy
  • Ordering
The Australian Monitor LRS series covers high power, all weather projection speakers for outdoor paging and background sound. Well suited to open air locations such as transport hubs, sports facilities and outdoor precincts. LRS8 and LRS12 share the same IP66 rated housing, mounting bracket and sealed connection panel, and both switch between 8Ω, 70V and 100V line to suit the install. The LRS12 steps up in power and reaches lower in frequency, for larger areas needing more output.

FEATURES

  • 8 inch two-way design
  • 8Ω, 70V and 100V line switchable
  • Multiple power tappings per model
  • IP66-rated weatherproof housing
  • CE and UKCA compliant
  • Adjustable tilt/swivel wall mounting bracket with integrated safety wire point
  • Locking handle for secure aiming
  • Sealed connection panel, screw terminals
  • Powder-coated SUS304 stainless steel bracket and grill

SPECIFICATIONS

MODEL LRS8
POWER (CONTINUOUS, PROGRAM, PEAK) 150W, 300W, 600W
TAPPINGS 150W - 67Ω
75W - 133Ω,
38W - 267Ω, 8Ω
ACOUSITC DATA
FREQUENCY RESPONSE (-3dB) 70Hz - 20kHz
SENSITIVITY  (1W/1M) Half Space 96dB
MAXIMUM SPL 1W/1M
(Continuous/Program/Peak)
118dB/121dB/124dB
DISPERSION 84° horz; 55° vert
TRANSDUCER
DRIVERS 1 x 8” / 2” voice coil LF
1 x 1” / 1” voicecoil HF
CROSSOVER 3kHz passive
PHYSICAL & ENVIRONMENTAL
CONSTRUCTION Housing - PP plus 30% fibreglass
IP RATING IP66
FINISH & COLOUR Powder-coated SUS306 stainless steel; White (RAL9016)
INPUT CONNECTOR 4 way Screw Terminal Block Cable up to 12-22AWG
OPERATING TEMPERATURE -25 °C to +70 °C
RELATIVE HUMIDITY 45% to 85 %
PRODUCT & SHIPPING DIMENSIONS
PRODUCT DIMENSIONS  (W X D X H) Excl bracket 315.5 x 350 x 307.5mm
PRODUCT WEIGHT 11.5kg
SHIPPING DIMENSIONS (W X D X H) 392 x 385 x 410mm
SHIPPING WEIGHT 14kg
APPROVALS
IEC62368-1-2023
EN 62368-1:2014 + A11:2024
EN 60529:1991 + A1:2000 + A2:2013 + AC:2019
ACCESSORIES
Mounting Bracket with 4 screws
Sealed plate with PG11 gland and loopthrough knockout PG11 Gland for loopthrough
3mm safety retention wire rope. 500mm length M8 Bracket Bolts x 2
M5 Bolts x 3. (Bracket Tilt x2 and rention wire x 1
