Mechanical Arm Visualizer M15W Aver

Product Code: AF-M15W

Brand
Aver
RRP $1,079.00


Quantity In Cart:
Unit of Measure
EACH



1 Year
Technical Specifications
Brands AVer
Native Resolution 4K
  • Details
  • Downloads
  • Where to Buy
  • Ordering

AVerVision M15W


Power Your Teaching by Connecting in a Second

Mechanical Arm Wireless Visualizer (Document Camera)
The M15W is a visualizer (document camera) designed to facilitate learning at all education levels. The beautifully sleek, compact body of the M15W reflects the wild freedom of its Wi-Fi connectivity and stunning 13-megapixel camera with 4K, 60fps imaging. Creating an engaging and interactive learning experience in a second with M15W’s wireless advantage is a dream come true.

  • 4K 60fps
  • 13 MP
  • 23X Digital Zoom
  • Dual Band Wi-Fi
  • Rechargeable Li-ion Battery
  • 3-Year Warranty

13-Megapixel Camera with 4K Quality
The 13-megapixel camera delivers 4K Ultra HD 60fps output resolution, creating remarkably detailed images of any object. Enjoy breathtaking video with no lag.

Fantastic USB Camera for Distance Learning
The M15W’s extremely compact and lightweight design makes it the best USB camera for boundary-free distance learning. It even includes a highly convenient rechargeable battery so you can just grab it and get online!

Highly Flexible Foldable Arm
The flexible and adjustable arm allows users to capture A3 or larger papers. Also, never worry about upside-down images again. Thanks to the position indicator on the camera head, teachers can always rock an accurate and efficient display.

Wired or Wireless — Whichever You Prefer
Not a fan of wireless connection or don’t have an ideal Wi-Fi environment? No problem. Teachers can visualize materials from multiple devices via USB or HDMI connections. Changing teaching behavior should be the least of your concerns.

AVerTouch Software
Here comes AVer’s latest and most powerful software—AVerTouch. All it takes is one touch to connect the M15W with mobile devices for content sharing, and teachers can connect to the cloud to automatically save annotated, captured, and recorded files.

Specs

  • Image sensor: 1/3.06" CMOS
  • Total pixels: 13 megapixels
  • Frame rate: 60 fps (max.)
  • Output resolution: 4K / Full HD 1080p 60Hz / HD 720p 60Hz
  • TV lines: 1400
  • Zoom: Total 23X (max.)
  • Focus: Auto / Manual / Area (via software)
  • Shooting area: A3 (426 x 313 mm at 330 mm)
  • Image rotation: 0° / 90° / 180° (rotate by camera head)
  • Preview mode: Normal / Motion / High Quality
  • Effect: Rotate / Freeze
  • Dual mode: AP / Station DHCP (Server / Client)
  • Wi-Fi streaming: 1080p 30 fps / up to 4K 30 fps
  • Dual band: 5 GHz / 2.4 GHz
  • Miracast: Yes
  • Compatibility: 802.11a/b/g/n/ac (45 ft effective range)
  • Wireless security: Support WEP, WPA/WPA2-PSK, WPA/WPA2-Enterprise (EAP-PEAP, EAP-TLS)
  • Image effects: Color / B&W / Negative
  • Image adjustments (white balance / exposure): Auto / Manual
  • Recording: Yes, via software
  • Capture: Yes, via software
  • Annotation: Yes, via software
  • Timer: Yes, via software
  • Picture-by-picture: Yes, via software
  • Capture mode: Single, via software
  • User profile: 1
  • Flicker filter control: Yes
  • ePTZ: Yes, via software
  • Cloud library: Yes, via software
  • USB bus power: Yes, standby only
  • Lamp type: LED light
  • MIC: Built-in
  • USB:
    • USB 2.0 Type A (Wi-Fi Dongle)
    • USB Type mini-B *1
  • Dimensions (L x W x H):
    • Operating: 518 mm (L) x 84 mm (W) x 351 mm (H)
    • Folded: 280 mm (L) x 84 mm (W) x 42 mm (H)
  • Weight: 0.68 kg (1.5 lbs)
  • Warranty:
    • Visualizer: 3 years
    • Battery and accessories: 1 year
  • Power source:
    • DC 5V/2A
    • AC 100-240V
  • Consumption:
    • 4 Watts (lamp on)
    • 3.5 Watts (lamp off)
  • Windows® OS: Windows® 7, 10, 11
  • Mac® OS: macOS® 10.15 or later
  • iOS: iOS v11 or later (iPad only)
  • Android™ OS: Android v5.0 or later
  • Optional accessories:
    • Carrying bag
    • Anti-glare sheet
  • Package Contents:
    • AVerVision M15W unit
    • Quick guide
    • USB cable
    • Power adapter (DC 5V)
    • Warranty card
